21.2cbm Liquid Argon Semi Trailer 3 Axles Trailer Truck

21.2cbm Liquid Argon Semi Trailer 3 Axles Trailer Truck

Short Description:

Semi trailer is 3 axles semi trailers, a kind of heavy traffic transportation tool by the traction pin connects with trailer head together . Semi trailers is mainly using for loading big volumen and not easy to disassemble, for example excavator etc engineering machinery. The cargo semi trailers including tipper semi trailers, stake semi trailers , flatbed semi trailers , container semi trailers etc , tanker semi trailers including oil tanker semi trailers , bulk cement semi trailers etc . Al...


Product Detail

FAQ

Product Tags

Semi trailer is 3 axles semi trailers, a kind of heavy traffic transportation tool by the traction pin connects with trailer head together . Semi trailers is mainly using for loading big volumen and not easy to disassemble, for example excavator etc engineering machinery. The cargo semi trailers including tipper semi trailers, stake semi trailers , flatbed semi trailers , container semi trailers etc , tanker semi trailers including oil tanker semi trailers , bulk cement semi trailers etc . All the kinds of semi trailers ( from light loading semi trailers to heavy loading semi trailers ) , we all can customize them according to customer’s special demands ( required dimensions , loading capacity etc  ) .

Tanker Essential Information
Dimensions(length*width*height)  11180*2500*3410mm
Estimated Tare Weigh Curb Weight 13760
Payload 26240
Total Weight 40000kgs
Tank Volume 21.2m3
Traction pin height from the ground 1320mm
Adiabatic way Vacuum \ multi-layer adiabatic
Adiabatic materials Aluminum foil, adiabatic paper
(Relief valve) opening pressure(Mpa) 0.8Mpa
Shell Of Tanker
Filling medium Liquid Argon(LAr)
Fluid property Liquefied
Design temperature                   -196
Design pressure 0.85MPa
Corrosion allowance          0mm
Major materials of bearing pressure S30408
Dish end plate material and thickness 7mm30408\Q345R)
Dish end weight(KG) 2*225
Inner tank Inside tank material S30408
Inner tank body thickness(mm) 10mm
Inner tank body weight(KG) 4230kgs
Tank shell Tank shell material Q345R
Tank shell weight(KG) 3720
Filling weight per volume 21.2m3
Weld joint factor 1.0 mm
Detection
Flaw detection 100% Flaw detection
Gas-tight test pressure 0.85MPa
control system
Safety Valve 2set ,DAY-25  0.92MPa
Valve and pipe Detail As customer’s requirement
Low-temperature shut-off valve 7sets Air DJL-40D      Liquid DJL-40D  Pressurize DJL-32D
emergency shutoff valve 3 sets  QGJ43F-25-8 & QGJ43F-25-7
liquidometer 1set 0-2500mm MZC-ⅡA
 indicating pressure gauge 1 set  YTN-100T 0—1.6MPa Accuracy 1.6 degree
Running System
Axles 13 TON FUWA Axles *3 unit
Suspension system FUWA leaf spring suspension
Wheel rim 9.0*22.5  * 12pieces
Tyre Double Coin 12R22.5  * 12 pieces
Kingpin 3.5″, 90# bolt on ,in rubbing plate
Landing legs FUWA 28T single linkage, Gear type * 2 piece
Pneumatic Brake System
Spring brake chamber FUWA brand * 6 pieces(4double+2single)
Air connector FUWA brand * 2 pieces
Relay Valve 1 pieces
ABS ABS 1 pieces
Electronical System
7-Pin Socket 24V 7-pin socket one set
LED Lamp led All kinds of lamp
Cable Stander cable  1 set
Accessories
Fire extinguisher 2sets 5Gg
Anti-static drag ground Model C
Small Tool box 1 set
Tools   Spare wheel up-down regulator Spare tire crank Leg crank

Tire socket spanne

Shaft head socket spanner

Warranty period
TERMS
Payment terms: 30%TT in advance,the balance should be paid before loading in factory.
Terms of delivery: in 30 days after the seller received 30% advance payment (try deliver the goods as soon as possible)
PORT:Tianjin or Qingdao or Shanghai

If you have more question about our product, Please write to me.Good quality, low price, Excellent service.Looking forward to your any inquiry!!


  • Previous:
  • Next:

  • Q:How to transport the truck?
    A:We mainly transport it by ro-ro ship or bulk ship.
    Q:I want to transport the truck by container, is it ok?
    A:Yes, it is ok .But we need take apart the truck.You should reinstall in your country.
    Q:How about your product quality?
    A:All our spare parts are from the original manufacturers, the quality is 100% guaranteed.

    Q:What is the payment term?

    A:Now the payment term we can accept is by T/T or L/C.

    Q:Can you provide after-sale service?

    A:Yes,of course,no matter it’s truck,construction machinery or spare parts,once we sell that to customers,we can provide after-sale service for customers,it means that if our products have related problems,just contact with us,we will try to solve that for customers and give the customers satisfied reply,since we are looking forward to long-term stable cooperation with customers.
