Container Transport Semi-trailer

Container Transport Semi-trailer

Short Description:

Semi trailer is 3 axles semi trailers, a kind of heavy traffic transportation tool by the traction pin connects with trailer head together . Semi trailers is mainly using for loading big volumen and not easy to disassemble, for example excavator etc engineering machinery. The cargo semi trailers including tipper semi trailers, stake semi trailers , flatbed semi trailers , container semi trailers etc , tanker semi trailers including oil tanker semi trailers , bulk cement semi trailers etc . Al...


Product Detail

FAQ

Product Tags

Semi trailer is 3 axles semi trailers, a kind of heavy traffic transportation tool by the traction pin connects with trailer head together . Semi trailers is mainly using for loading big volumen and not easy to disassemble, for example excavator etc engineering machinery. The cargo semi trailers including tipper semi trailers, stake semi trailers , flatbed semi trailers , container semi trailers etc , tanker semi trailers including oil tanker semi trailers , bulk cement semi trailers etc . All the kinds of semi trailers ( from light loading semi trailers to heavy loading semi trailers ) , we all can customize them according to customer’s special demands ( required dimensions , loading capacity etc  ) .

       Container Transport Semi-trailer
Tare weight 9000kg
Payload 20000kg+40000kg
Overall length 19450mm(6200mm+950mm+12300mm)
Overall width 2500mm
Overall height 3000mm
SPECIFICATION
Chassis Heavy duty and extra durability designed I beam; opting for high tensile steel, welded by automatic submerged-Arc processes. Top flange 12mm,width140mm;Middle Flange 6mm;bottom flange14mm,width 140mm
Axle 5(2+3), FUWA,13T
Suspension Mechanical suspension
Leaf spring Leaf spring
Floor 3mm  side wall:2mm
Tire 12.00R24  20pcs(8+12)
Wheel rim 8.5-24     20pcs(8+12)
Kingpin 2’’ bolt-in king pin
Landing gear FUWA two-speed, manual operating ,heavy duty landing gear 28T
Twist lock 16pcs of  ISO twist locks for 1x20ft,2x20ft,1x40ft container
Vehicular applications Cargo transport
Drawing Including
Braking system WABCO RE6 relay valve ;T30/30 spring brake chamber;40L air tanks
Painting Complete chassis sand blasting to clean rust ,1coat of anticorrosive prime,2coats of final paint
Accessories One standard tool box

If you have more question about our product, Please write to me.Good quality, low price, Excellent service.Looking forward to your any inquiry!!


  • Previous:
  • Next:

  • Q:How to transport the truck?
    A:We mainly transport it by ro-ro ship or bulk ship.
    Q:I want to transport the truck by container, is it ok?
    A:Yes, it is ok .But we need take apart the truck.You should reinstall in your country.
    Q:How about your product quality?
    A:All our spare parts are from the original manufacturers, the quality is 100% guaranteed.

    Q:What is the payment term?

    A:Now the payment term we can accept is by T/T or L/C.

    Q:Can you provide after-sale service?

    A:Yes,of course,no matter it’s truck,construction machinery or spare parts,once we sell that to customers,we can provide after-sale service for customers,it means that if our products have related problems,just contact with us,we will try to solve that for customers and give the customers satisfied reply,since we are looking forward to long-term stable cooperation with customers.
