31000L Liquid Nitrogen Tanker Semi Trailer

31000L Liquid Nitrogen Tanker Semi Trailer

Short Description:

Semi trailer is 3 axles semi trailers, a kind of heavy traffic transportation tool by the traction pin connects with trailer head together . Semi trailers is mainly using for loading big volumen and not easy to disassemble, for example excavator etc engineering machinery. The cargo semi trailers including tipper semi trailers, stake semi trailers , flatbed semi trailers , container semi trailers etc , tanker semi trailers including oil tanker semi trailers , bulk cement semi trailers etc . Al...


Product Detail

FAQ

Product Tags

Semi trailer is 3 axles semi trailers, a kind of heavy traffic transportation tool by the traction pin connects with trailer head together . Semi trailers is mainly using for loading big volumen and not easy to disassemble, for example excavator etc engineering machinery. The cargo semi trailers including tipper semi trailers, stake semi trailers , flatbed semi trailers , container semi trailers etc , tanker semi trailers including oil tanker semi trailers , bulk cement semi trailers etc . All the kinds of semi trailers ( from light loading semi trailers to heavy loading semi trailers ) , we all can customize them according to customer’s special demands ( required dimensions , loading capacity etc  ) .

Tanker Essential Information
Dimensions(length*width*height)  10610x2500x3820*7mm
Estimated Tare Weigh Curb Weight 16254
Payload 23746
Total Weight 40000kgs
Tank Volume 31000L
Unit volume filling weight(KG/L) 0.766
Traction pin height from the ground 1320mm
Adiabatic way Vacuum \ multi-layer adiabatic
Adiabatic materials  wind
(Relief valve) opening pressure(Mpa) 0.8Mpa
Shell Of Tanker
Filling medium Liquid Nitrogen
Fluid property Liquefied nitrogen
Design temperature                      50
Design pressure 0.91MPa
Working pressure 0.8MPa
Corrosion allowance             0mm
Major materials of bearing pressure S30408
Shape round
Compartments Single
Filling weight per volume 31000L
Weld joint factor 1.0 mm
Detection
Pressure test 1.17MPa
Flaw detection 100% Flaw detection
Gas-tight test pressure 0.91MPa
control system
Safety Valve 2set ,DAY-25  0.98MPa
Valve and pipe Detail As customer’s requirement
Low-temperature shut-off valve 5sets Air DJL-40D      Liquid DJL-40D  Pressurize DJL-32D
emergency shutoff valve 3 sets  QGJ43F-25-8 & QGJ43F-25-7
liquidometer 1set 0-1500mm MZC-ⅡA
 indicating pressure gauge 1 set  YTN-100T 0—1.6MPa Accuracy 1.6 degree
Running System
Axles 13 TON FUWA Axles *3 unit
Suspension system FUWA leaf spring suspension
Wheel rim 9.0*22.5  * 12pieces
Tyre Double Coin 12R22.5  * 12 pieces
Kingpin 3.5″, 90# bolt on ,in rubbing plate
Landing legs FUWA 28T single linkage, Gear type * 2 piece
Pneumatic Brake System
Spring brake chamber FUWA brand * 6 pieces(4double+2single)
Air connector FUWA brand * 2 pieces
Relay Valve 1 pieces
ABS ABS 1 pieces
Electronical System
7-Pin Socket 24V 7-pin socket one set
LED Lamp led All kinds of lamp
Cable Stander cable  1 set
Accessories
Fire extinguisher 2sets 8Gg
Static conductive belt Model C
Small Tool box 1 set
Tools   Spare wheel up-down regulator Spare tire crank Leg crank Tire socket spanne

Shaft head socket spanner

Warranty period
TERMS
Payment terms: 30%TT in advance,the balance should be paid before loading in factory.
Terms of delivery: in 30 days after the seller received 30% advance payment (try deliver the goods as soon as possible)
PORT:Tianjin or Qingdao or Shanghai

If you have more question about our product, Please write to me.Good quality, low price, Excellent service.Looking forward to your any inquiry!!


  • Previous:
  • Next:

  • Q:How to transport the truck?
    A:We mainly transport it by ro-ro ship or bulk ship.
    Q:I want to transport the truck by container, is it ok?
    A:Yes, it is ok .But we need take apart the truck.You should reinstall in your country.
    Q:How about your product quality?
    A:All our spare parts are from the original manufacturers, the quality is 100% guaranteed.

    Q:What is the payment term?

    A:Now the payment term we can accept is by T/T or L/C.

    Q:Can you provide after-sale service?

    A:Yes,of course,no matter it’s truck,construction machinery or spare parts,once we sell that to customers,we can provide after-sale service for customers,it means that if our products have related problems,just contact with us,we will try to solve that for customers and give the customers satisfied reply,since we are looking forward to long-term stable cooperation with customers.
