3.5 tons PG/Gasoline Forklift Truck

3.5 tons PG/Gasoline Forklift Truck

Short Description:

3.5Tons PG/Gasoline Forklift Truck Main Features : Max. Lifting capacity : 3500kg  3.5 Ton Max. Lifting height : 3000mm Power Type : Diesel With CE cetificate Good Quality and high working efficient Product Name 3.5 tons Gasoline/LPG Forklift Truck  Model CPQYD35FR Load capacity (kg) 3500 Load center (mm) 500 Power type Gasoline/LPG Max. lifting speeds ( with load )  mm/s 375 Max. driving speeds ( with/without load )  km/h 7/19 Max. towing ( with/without load )  kn 16/11...


Product Detail

FAQ

Product Tags

3.5Tons PG/Gasoline Forklift Truck

Main Features :

  1. Max. Lifting capacity : 3500kg  3.5 Ton
  2. Max. Lifting height : 3000mm
  3. Power Type : Diesel
  4. With CE cetificate
  5. Good Quality and high working efficient
Product Name 3.5 tons Gasoline/LPG Forklift Truck
Model CPQYD35FR
Load capacity (kg) 3500
Load center (mm) 500
Power type Gasoline/LPG
Max. lifting speeds ( with load )  mm/s 375
Max. driving speeds ( with/without load )  km/h 7/19
Max. towing ( with/without load )  kn 16/11
Gradeability (with/without load )  % 15/20
Lifting height (mm) 3000
Free lift (mm) 80
Tilting angles ( forward-backward )  (  .) 6/12
Min. turning radius (mm) 2500
Min. right angle aisel width ( mm ) 2110
Min. under-clearance (mm) 135

Dimension
Overall length (including fork)mm 3800
Overall width ( mm ) 1230
Overall height (mast lowered )mm 2110
Overall height (mast extend )mm 4270
Overall height to overhead guard (mm) 2110
Fork overhang (mm) 465
Wheel base (mm) 1750
Tread Front tread (mm) 1000
Rear tread (mm) 970
Tyre Front tyre 28.9-15
Rear tyre 6.50-10
Total weight (kg) 4580
Fork width (mm) 125
Fork thickness (mm) 50
Backrest height (mm) 1225
Fork length (mm) 1220
Engine Engine model K25/Chinese GQ4Y/Chinese BY491GP
Rate power (KW) 37.4/41/41
Type of power shift Tor-non
Optional Side Shifter




  • Previous:
  • Next:

  • Q:How to transport the truck?
    A:We mainly transport it by ro-ro ship or bulk ship.
    Q:I want to transport the truck by container, is it ok?
    A:Yes, it is ok .But we need take apart the truck.You should reinstall in your country.
    Q:How about your product quality?
    A:All our spare parts are from the original manufacturers, the quality is 100% guaranteed.

    Q:What is the payment term?

    A:Now the payment term we can accept is by T/T or L/C.

    Q:Can you provide after-sale service?

    A:Yes,of course,no matter it’s truck,construction machinery or spare parts,once we sell that to customers,we can provide after-sale service for customers,it means that if our products have related problems,just contact with us,we will try to solve that for customers and give the customers satisfied reply,since we are looking forward to long-term stable cooperation with customers.
